Humidity and Temperature Transmitters HMD60

HMD62 Humidity and Temperature Transmitter

HMD60 series transmitter with a short probe held in a hand

Humidity and Temperature Transmitters HMD60

±1.5%RH Transmitters for Demanding HVAC, with a Certificate

The sturdy and reliable duct mounted Vaisala HUMICAP® Humidity Transmitter Series HMD60 is designed for monitoring relative humidity in demanding HVAC and light industrial applications. The combination of high accuracy, stability and reliable operation makes this product series an ideal choice for demanding applications.

The models in this series are:

HMD62 for measuring humidity and temperature
TMD62 for measuring temperature only
HMD65 for measuring humidity and temperature with BACnet and ModBus protocols
HMD60 for measuring humidity and temperature with a short probe, fully configurable
TMD60 for measuring temperature only with a short probe, fully configurable

All these duct-mounted transmitters are robust and reliable, designed for use in demanding HVAC and light industrial applications. The transmitter is resistant to chemicals and dust, and the all-metal body is IP66-rated.

All common humidity parameters are available in the HMD60: dew point, wet bulb, enthalpy, absolute humidity, mixing ratio. All these parameters can be selected using DIP-switches.

Field adjustment is easy with the high precision trimmers or using the Vaisala HUMICAP® Hand-held Humidity and Temperature Meter HM70. The transmitter is also configurable using the Vaisala Insight PC Software.

The combination of high accuracy, stability and reliable operation makes this product series an ideal choice for museums, cleanrooms and laboratories to mention a few examples. The products come with a traceable calibration certificate.

For specifications, see the datasheet.

Watch also the video of HMD60 in NEMA 4X test.

View all Vaisala prodoucts for HVAC.

Buy Now

Watch the video

Vaisala Hardware Testing

Key Benefits

Robust Design, Stable and Reliable

The all-metal body of the transmitter is well suited for use at building sites and industrial settings. HMD60 series provides state-of-the-art stability and environmental resistance thanks to the Vaisala HUMICAP® R2 sensor. The measurement accuracy is up to ±1.5 %RH and ±0.1 °C (±0.18 °F). All common humidity parameters are available, including RH, dew point, enthalpy, and wet bulb temperature.

Fast On-Site Calibration

The accuracy of the transmitters is simple to check using Vaisala's handheld meter HM70. The calibration takes only seconds with a single potentiometer without disturbing the operation, saving in both maintenance time and costs.

Usability

Vaisala Insight PC software allows the easy configuration of the HMD60 series either by users or at the factory. Electronics can be removed without removing the unit from the duct. The products are configurable using the Vaisala Insight PC Software.

Overview

The duct mount HMD60 series transmitters can also be used in many industrial humidity monitoring applications, where their stability and resistance to chemicals and dust are of great value. A useful feature of these duct mount transmitters is the ability to remove the electronics without removing the unit from the duct.

The following old models are replaced with new ones:

HMD60U and HMD60Y are replaced by the HMD62 for the 4 … 20 mA model.
HMD60T is replaced by the TMD62.
HMD70U and HMD70Y are replaced by the HMD65

Features

Measurement accuracy up to ±1.5 %RH and ±0.1 °C (±0.18 °F)

Analog output 4 … 20 mA transmitter model options: HMD62 (RH and T) and TMD62 (T-only)

Analog output 0 … 10 V transmitter model: HMD65 (RH and T)

BACnet MSTP and Modbus RTU: HMD65

Resistant to chemicals and dust

IP66-rated body

Traceable calibration certificate

Easy field adjustment and output configuration with quick access to transmitter electronics also when installed

Compatible with Vaisala Insight PC software
